Supersport Segment

GYTR Performance Products
Full Range and Set Up Manuals


GYTR banner
DOWNLOAD: 2019 YZF-R1/ YZF-R6/ YZF-R3 Full Product Catalog

GYTR SS HEADER

R1 GYTR banner
DOWNLOADS:
2019 YZF-R1 Kit Manual
FI Matching System Manual - Version 2.13
* Selection of available parts shown below. Full product range available in catalog.

Air Funnel Set

2CR-1440B-70

- This part is a set consists of a primary funnel and variable secondary funnel.
- Important: Check the R1 Parts Combination for the combination.
- No other combination is allowed to use.



Spark Plug Set

14B-R465B-70

- Set of 4 spark plugs R0465B-10 of NGK.(Semi-surface discharge)




ECU Set for 2018 - 2019 model

BX4-8591A-7100

- Allows adjustment the amount of fuel injection and ignition timing.
- CD-ROM, software manual and kit manual are included in this set.
- Blipper functionality now added.
- Important: Check the R1 PARTS COMBINATION TABLE for the combination.




Gear 6th Pinion B

2CR-17161-80

- Range of gears available
- Please refer Kit R1 Mission Ratio sheet for details
- You can order each gear individually.




Mission Maintenance Set

2CR-A7000-70

- Suitable from 2015 to 2018 model years
- This set includes 5 sets of circlips and 3 sets of collar, washers and bearings.




Headlight Harness Set

BX4-F4350-70

- For Endurance Racing
- Consists of two circuits in the system.
- This set has an independent switch to turn on the taillight in case of emergency.
- Use this set together with the kit wire-harness.




Cushion Seat

13S-24713-70

- For Racing usage
- This cushion seat is nonslip type sponge with dimples.




CCU (Communication Control Unit) Set

2KS-85800-71

- KIT that has a function of analogue channel (2 channels) added to the CCU of 2KS (YZF-R1M).
- This can be used to measure air-fuel ratio or suspension stroke amount, etc.
- Sensors necessary for the measurement have to be purchased separately
- Firmware is upgraded from '-70'

R6 GYTR banner

DOWNLOADS:
2019 YZF-R6 Kit Manual
FI Matching System Manual - Version 2.13
* Selection of available parts shown below. Full product range available in catalog.

Spark Plug Set

5FL-R045Q-70

- Set of 4 spark plugs R0045Q-10 of NGK.(Semi-surface discharge)




Cylinder Head Gasket (t=0.45mm)

2C0-11181-76

- Gasket is made to adjust the squish height.
- Tolerance of 0.45mm compared to 0.60mm on standard component




Camshaft 1 (Intake), modified duration, standard lift

2C0-12171-73

- Working angle , lift and Cam-profile have been changed to improve output.
- Important: Check the R6 Parts Combination for the combination.
- No other Combination is allowed to be used.




Camshaft 2 (Exhaust), modified duration, standard lift

2C0-12181-71

- Working angle , lift and Cam-profile have been changed to improve output.
- Important: Check the R6 Parts Combination for the combination.
- No other Combination is allowed to be used.




Cover, with improved ground clearance (included in ACM SET)

2C0-15411-71

- Part for repair (included in ACM set)




Oil Pump Assembly

2C0-13300-70

- For Race usage
- Oil pump generates higher oil pressure.




Throttle Body Clamp Assembly

2C0-1351A-70

- For Race usage
- For easy disassembly of the throttle body from the engine.




Friction Plate Set

2C0-A6321-70

- This plate is designed to improve clutch feeling and durability.
- 1 set contains 9 plates.




Axle Main A

2C0-17411-80-A

- Range of gears available
- Please refer Kit R6 Mission Ratio sheet for details
- You can order each gear individually.



R3 GYTR banner

DOWNLOADS:
2019 YZF-R3 Kit Manual
* Selection of available parts shown below. Full product range available in catalog.

* NEW - 2019 - Full Engine Kit

B7P-RACE3-19-00

- Available for EURO4 – EURO3 models
- You can order each part individually. Please refer to the product range brochure for details.
